Trying to figure out how professional prints are so thin

Like Tree7Likes
  • 1 Post By splathead
  • 5 Post By PatWibble
  • 1 Post By multiplesifl


Share This Thread Thread Tools
Old September 8th, 2019 Sep 8, 2019 10:19:06 AM -   #1 (permalink)
T-Shirt Lover
T-Shirt Aficionado

Mdrake's Avatar

Member Since: Aug 2013
Posts: 140
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Thanks: 3
Thanked 2 Times in 2 Posts


Default Trying to figure out how professional prints are so thin

Ive been screen printing for about 9 months using plastisol ink only. Unfortunately, I’ve had some complaints about the thickness of my prints on some of the larger designs. I have this problem even when I only hit the underbase once.

I visited a few stores to take a look at some professionally printed shirts and every single one is definitely thinner than mine. For example, a large rectangular design, with the whole rectangle filled with ink (underbase and overprint) felt way thinner than all of my prints.

Could these thin prints just be waterbased inks? From the comments I’ve seen on here, I assumed waterbased inks have no hand. Or is there something I could be doing wrong? All I can say is I use Wilflex white ink and Union color inks.

Sponsored Links
Advertisement

Old September 8th, 2019 Sep 8, 2019 7:57:53 PM -   #2 (permalink)
Super Moderator
Certified T-Shirt Junkie

splathead's Avatar  - this member was voted Most Helpful Member during our Annual August Member Appreciation Month

You can call me: Joe
Member Since: Dec 2005
Location: San Antonio
Posts: 13,569
Mentioned: 33 Post(s)
Tagged: 0 Thread(s)
Thanks: 273
Thanked 2,515 Times in 2,233 Posts


Default Re: Trying to figure out how professional prints are so thin

They could be waterbased.


Or discharged, eliminating the need for a white underbase.


Or a curable reducer that 'thins' out the ink and gives it less of a hand.
seacookie likes this.
__________________
Joe
www.splathead.com

Old September 9th, 2019 Sep 9, 2019 1:28:03 AM -   #3 (permalink)
Senior Member
Certified T-Shirt Junkie


PatWibble's Avatar

You can call me: Pat
Member Since: Mar 2014
Location: South West England
Posts: 1,977
Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Thanks: 67
Thanked 384 Times in 363 Posts


Default Re: Trying to figure out how professional prints are so thin

A lot of 'new' printers start with a very low mesh count leading to laying down a lot of ink. Are you using 110t ( 43t/cm) mesh? You need to have the confidence to increase it to somewhere between 160 - 200t as your standard mesh count.



Thin your inks accordingly, but mix well first. Plastisol is 'thixotropic', meaning it becomes more fluid when stirred. Stick a wooden spoon into the chuck of a cordless drill and whizz the nuts out of your ink.


Old 2 Weeks Ago Sep 25, 2019 11:45:20 AM -   #4 (permalink)
T-Shirt Lover
T-Shirt Fan

dhiggi12's Avatar

Member Since: Nov 2011
Location: Ohio
Posts: 43
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Thanks: 0
Thanked 6 Times in 6 Posts


Default Re: Trying to figure out how professional prints are so thin

Quote:
Originally Posted by PatWibble
A lot of 'new' printers start with a very low mesh count leading to laying down a lot of ink. Are you using 110t ( 43t/cm) mesh? You need to have the confidence to increase it to somewhere between 160 - 200t as your standard mesh count.



Thin your inks accordingly, but mix well first. Plastisol is 'thixotropic', meaning it becomes more fluid when stirred. Stick a wooden spoon into the chuck of a cordless drill and whizz the nuts out of your ink.



never stick anything in your inks other than metal or plastic or coated cardboard clean up cards.Wood will leach plasticize rs from the ink.

Old 2 Weeks Ago Sep 25, 2019 12:18:32 PM -   #5 (permalink)
Senior Member
T-Shirt Mogul


seacookie's Avatar

Member Since: Apr 2015
Posts: 1,140
Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Thanks: 97
Thanked 115 Times in 109 Posts


Default Re: Trying to figure out how professional prints are so thin

I went to pick up at my local store for running equipment for my self. I ordered online, but they are local so I pick stuff cause I am cheap and I save for shipping that way.


When I was waiting for my stuff i seen 2 nike hoodies with Celtics logo on it.


Hoodie was exactly like this one except inside of that logo, there were many small white dots to fill the space inside. They were quite a part from each other.




I spend 3 minutes for inspecting that hoodie. Design was quite thick and the weird part was, that inside of that logo,where lots of tiny dots were ''printed'', all that empty space around dots felt like it's something on that hoodie. It felt very unbreathable. I was thinking if maybe that's a vinyl on that hoodie... But that green inside of that logo was covered with something...

Old 2 Weeks Ago Sep 26, 2019 4:24:34 AM -   #6 (permalink)
T-Shirt Lover
T-Shirt Fan

multiplesifl's Avatar

You can call me: Trisha
Member Since: Jun 2011
Location: Caribou, ME
Posts: 37
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Thanks: 11
Thanked 1 Time in 1 Post


Default Re: Trying to figure out how professional prints are so thin

They probably used a clear ink for the underbase on that hoodie.

As for OP, if you want to reduce the hand on your prints but don't wish to move away from plastisol, try heat pressing the garments after printing. It helps flatten the thickness a bit.
seacookie likes this.
__________________
I smell burning pallet.

Old 2 Weeks Ago Sep 26, 2019 5:51:22 PM -   #7 (permalink)
Senior Member
Certified T-Shirt Junkie


NoXid's Avatar

Member Since: Apr 2011
Location: Portland OR USA
Posts: 2,994
Mentioned: 25 Post(s)
Tagged: 0 Thread(s)
Thanks: 150
Thanked 543 Times in 517 Posts


Default Re: Trying to figure out how professional prints are so thin

You can generally tell Plastisol from water base because Plastisol will fill in the grooves/valleys of the weave, whereas water base conforms to the grooves/valleys of the weave leaving them visible rather than a smooth surface.
__________________
How To - Calculating Exposure Time
